Product Overview
The 100W LDMOS Counter-UAV Jamming Module (500–600MHz) is a high-power RF interference module designed for professional drone countermeasure and signal shielding systems. Utilizing advanced LDMOS power amplifier technology, this module delivers stable 100W output power with wide voltage tolerance and excellent thermal performance.
Equipped with a built-in high-speed noise modulation signal source, the module supports fast analog sweep jamming, effectively disrupting drone control and data links operating in the 500–600MHz band. Its compact structure, reliable protection mechanisms, and customization flexibility make it ideal for fixed, mobile, or integrated anti-drone platforms.
Key Features
-
100W high-power LDMOS design for long-range UAV interference
-
500–600MHz operating frequency, customizable on request
-
Built-in high-speed noise modulation signal source
-
Adjustable analog sweep speed (100–500kHz optional)
-
Wide 28–32V DC power input
-
Compact size and rugged construction for system integration
-
Integrated over-voltage and over-temperature protection
-
LED indicators for real-time operating status
Technical Specifications
| Item | Specification | Notes |
|---|---|---|
| Operating Frequency | 500–600MHz | Customizable |
| Output Power | 50 ±1 dBm (100W) | Continuous output |
| Power Amplifier Type | LDMOS | High efficiency |
| Operating Voltage | 28V DC | Range: 28–32V |
| Operating Current | ≤9.2A | @100W output |
| Signal Source | Built-in high-speed noise modulation | Optional VCO / DDS / SDR |
| Analog Sweep Speed | 270kHz | Customizable: 100–500kHz |
| Operating Temperature | -20℃ to +65℃ | Normal operation |
| RF Connector | N-Female | Low-loss output |
| Status Indicators | Power, Over-Voltage, Over-Temperature | LED display |
| Dimensions | 150 × 80 × 22 mm | Compact design |
| Weight | 800 g | Lightweight |
Applications
-
Counter-UAV and anti-drone systems
-
RF signal shielding and electronic countermeasures
-
Fixed or vehicle-mounted drone defense platforms
-
Integrated jammer guns and modular interference systems
-
Security protection for sensitive facilities and airspace
Customization Options
This 500–600MHz LDMOS jamming module supports extensive customization, including:
-
Frequency range adjustment
-
Sweep speed configuration
-
Alternative signal sources (VCO, DDS, SDR)
-
Mechanical and interface adaptations for system integration
Conclusion
The 100W 500–600MHz LDMOS Drone Jammer Module delivers powerful, stable, and efficient RF interference performance in a compact and customizable design. It is a reliable core module for professional counter-UAV systems requiring high output power, fast sweep response, and long-term operational stability.
