PRODUCT INTRODUCTION
The BQX-FK-BTD08 Trolley Case Electronic Containment Device (8-channel) is designed for special environments with limited space and no power supply, where vehicle-mounted jammers cannot operate. It utilizes advanced digital radio technology, DSP, power amplification, and high-gain antenna design to effectively counter RCIEDs (Remote Controlled Improvised Explosive Devices). With optimized transmission power and jamming distance, it provides efficient electronic countermeasure solutions.
20-6000MHz Full-band Coverage
Enables point-to-point configuration for any frequency or channel with zero blind spots; supports customizable frequency/power settings for various applications.
360° Omnidirectional Jamming
High-gain omnidirectional antenna provides complete radio signal coverage over 360° range.
Multi-Purpose Device
Functions as EOD jammer, UAV countermeasure, signal blocker, walkie-talkie/WiFi/Bluetooth/broadcast jammer.
Dual Power Supply
Supports both AC mains and internal/external battery packs with seamless switching.
High-Power 8-Channel Jamming
Eight independently controllable channels with ≥450W total output power; single-channel on/off support.
Flexible Frequency/Power Adjustment
Frequency and power settings can be modified by replacing corresponding modules.
Trolley Convenience Design
Integrated modular structure enables quick disassembly/reassembly (<5 minutes) for rapid maintenance.
High Scalability
Supports per-channel power boost, custom modules, and multi-device networking.
 |
|||
| PERFORMANCE INDEX | |||
| Operating Mode | Comb spectrum, Frequency sweep | ||
| Jamming Mode | Fully digital (DDS) signal synthesis technology | ||
| Output Channels | 8 omnidirectional channels with individual control | ||
| Jamming Type | Sweep frequency interference | ||
| Working Mode | Full-band or sub-band operation per mission needs | ||
| Antenna Type | High-gain omnidirectional 360° external antenna | ||
| RF Power Range | 20-100MHz: 100W±5W | ||
| 100-500MHz: 91W±5W | |||
| 500-1000MHz: 78W±5W | |||
| 1000-2700MHz: 40W±4W | |||
| 1800-2200MHz: 40W±4W | |||
| 2500-2700MHz: 40W±4W | |||
| 5725-5850MHz: 40W±4W | |||
| 2700-6000MHz: 40W±4W | |||
| Total Output: ≥450W | |||
| Jamming Direction | 360° omnidirectional | ||
| Jamming Radius | 20-100m (environment-dependent) | ||
| Power Consumption | MAX 1500W | ||
| Structure | Modular design for quick maintenance and upgrades | ||
| Protections | RF: No-load/short-circuit protection Power: Undervoltage/overvoltage/overload/short-circuit protection |
||
| Power Supply | AC220V mains / DC24-28V battery | ||
| Weight | ≤60KG (including battery) | ||
| Operating Temp | -25°C ~ +55°C | ||
| Humidity | 80%±5 RH | ||
| Cooling System | Intelligent cooling fans + heat sinks for stable operation | ||
| Reliability | MTBF ≥1000hrs, MTTR ≤1hr | ||
