5700~5900MHz Digital Signal Source Module
Precision Signal Generation Solution for Wi-Fi 6E Extended Band Drone Jamming Systems
The SZMS5759HF1 is a high-precision digital signal source module engineered for 5700~5900MHz Wi-Fi 6E extended frequency generation, delivering exceptional signal quality with 0.5dB power adjustment steps. This advanced module features RS485 control interface and 7W2 power control connector, making it ideal for integration into professional drone jammer systems. With its compact 146×63×17.5mm form factor and low power consumption (200mA @28V), this UAV jammer module component provides reliable signal generation for Backpack Drone Jammer systems, Portable Anti-Drone Stations, and Tactical UAV Jammer Backpacks. Comprehensive documentation includes detailed instructions on how to use this signal source module effectively within drone jamming systems, including integration with Wearable Drone Defender configurations.
Model: SZMS5759HF1
Detailed Technical Specifications
| Parameter |
Specification |
| Signal Type |
Digital Signal Source |
| Operating Frequency Range |
5700~5900MHz |
| Maximum Output Power |
10dBm |
| Output VSWR |
≤2.0 |
| Operating Voltage Range |
DC 12V ~ 29V |
| Maximum Operating Current |
200mA @28V |
| Power Adjustment Range |
0~31.5dB |
| Power Adjustment Step |
0.5dB |
| Output Interface |
SMA Female |
| Power Control Connector |
7W2 |
| Control Interface |
RS485 |
| Dimensions |
146 × 63 × 17.5 mm |
| Weight |
0.21 kg |
5700~5900MHz Digital Signal Source Module SZMS5759HF1
Core Features
Wi-Fi 6E Extended Band Precision Signal Generation
This drone jammer module component delivers precise signal generation across 5700~5900MHz Wi-Fi 6E extended band with 0.5dB power adjustment steps, providing exceptional signal quality for anti-drone system applications targeting Wi-Fi 6E extended communication frequencies used by modern drones.
Advanced Control Interface
RS485 control interface enables flexible integration into comprehensive drone jamming systems, allowing remote management and configuration in Portable Anti-Drone Systems and Tactical UAV Jammer Backpacks.
Low Power Consumption
Maximum operating current of only 200mA @28V ensures efficient power utilization, making it ideal for battery-powered Wearable Drone Defender applications.
Wide Power Adjustment Range
0~31.5dB power adjustment range with 0.5dB steps provides precise signal level control for various drone jamming scenarios and environments.
Compact Design
Ultra-compact dimensions (146×63×17.5mm) and lightweight construction (0.21kg) enable easy integration into space-constrained drone jammer module designs.
Stable Output Performance
Output VSWR ≤2.0 ensures reliable signal transmission and system stability in demanding Backpack Drone Jammer applications.
Application Areas
Drone Jammer Signal Source Systems
Portable Anti-Drone Communication Modules
Tactical UAV Jammer Control Systems
Wearable Drone Defender Signal Generation
Wi-Fi 6E Extended Band Electronic Warfare Equipment
Communication System Prototyping
RF Signal Analysis Equipment
Technical Highlights Summary
The SZMS5759HF1 digital signal source module provides precision signal generation across 5700~5900MHz Wi-Fi 6E extended band with 0.5dB power adjustment steps and 31.5dB dynamic range. Featuring RS485 control interface and ultra-low power consumption (200mA @28V), this compact module (146×63×17.5mm, 0.21kg) is ideal for integration into drone jammer systems including Backpack Drone Jammer configurations, Portable Anti-Drone Stations, and Tactical UAV Jammer Backpacks. As a drone jammer module for sale, it supports flexible system integration and comes with comprehensive documentation on how to use this signal source effectively in various anti-drone applications, including Wearable Drone Defender systems requiring precise Wi-Fi 6E extended band signal generation capabilities.
